ClassenAerator
TA22H Steerable Split-Drum Aerator
Steerable Split-Drum Series
Model TA22H
Working Width
21 in
Engine
Honda GX120
Power Source
Gas
Weight
270 lbs
Features
- The Classen steerable, split drum aerator employs a wide frame creating a large aerating width. The front drive of the machine features a split drum design which improves the machine maneuverability reducing operator fatigue.
- Dual front drums
- Quality of Core
- Steerable tine bank design
- Easy to maneuver and productive
- 2-year warranty
- Dual front drums provide exceptional maneuverability and eases end of row turning
- Steerable tine bank enhances maneuverability and eases end of row turning
- Balancing productivity and size, aerator easily passes through a 36" gate
- Fold-down handle for compact transport and storage
- Tie-down/lift handles ease transport
- Ergonomic foam grip handle for user comfort
- The unique tine engagement handle is easy to lift and lower
- Tine engagement lock prevents accidental tine drop during transport
- Easy to remove weights
- Honda GX120 Engine achieves the fastest speed in its class
Full Specifications
Engine
EngineHonda GX120
Power SourceGas
Fuel
Fuel Capacity0.5 gal
Performance
Working Width21 in
Max Aerating Depth3 in
Number of Tines36
Core Diameter0.75 in
Hole Pattern3.4 x 7 in
Holes per Sq Ft6.5
Max Productivity/Hour32,300 sq ft
Front Drum Diameter9.5 in HDPE
Drive
TransmissionBelt Drive
Ground Speed4.2 mph forward
Front Wheels StyleSolid Rubber
Rear Wheels8 in
Rear Wheels StyleSolid Rubber
Dimensions & Weight
Removable Weight Bars Each21.5 lbs
Dimensions46 x 30 x 48 in (L x W x H)
Folded Dimensions37 x 30 x 25 in (L x W x H)
Weight270 lbs
Warranty
Warranty2 years (engines warranted separately)
Classen
Classen is a Schiller Grounds Care brand of turf renovation equipment (aerators, sod cutters, overseeders and turf rakes), founded in Norfolk, Nebraska in 1973 and part of Schiller since 2004.
