ClassenOverseeder
TS-20eV Battery-Powered Overseeder
Battery-Powered Series
Model TS-20eV
Working Width
20 in
Power Source
Battery
Weight
150 lbs
Features
- Professional Overseeding. Powered for the Future.
- The Classen TS-20eV delivers the same precision seed placement, rugged construction and proven performance that turf professionals have trusted for decades—now powered by the Vanguard 48V commercial battery platform. Improve turf density and establish thicker, healthier turf with the same dependable performance you expect from Classen while eliminating engine emissions, reducing operating noise, lowering fuel costs and minimizing routine engine maintenance. Built for landscape contractors, rental fleets and turf professionals who demand dependable performance on every job.
- Commercial 48V, 1.5kWh battery delivers dependable power with zero engine emissions and the flexibility to swap batteries between compatible Classen equipment
- Recharge to 80% in just 50 minutes or reach a full charge in approximately 75 minutes, keeping crews productive throughout the day
- Battery is housed in a rugged die-cast aluminum enclosure that helps protect against dust, dirt, debris and the rigors of commercial use
- Backed by Vanguard's 8-year industry-leading commercial battery warranty for long-term confidence and reduced cost of ownership
- Industry-leading 1-1/2" blade spacing delivers exceptional seed-to-soil contact for improved germination and healthier, denser turf
- Reversible heat-treated blades can be rotated 180° to provide double the service life, reducing maintenance costs and downtime
- Elevated covered seed box is mounted higher on the machine to improve seed flow and help eliminate clogging
- Quick-release seed box design allows the seed box to be removed in seconds for fast cleanout and easy seed changes between jobs
- 5-Position single-action height adjustment allows operators to quickly set the working depth with a simple, single-lever adjustment to match changing turf conditions
- Two machines in one – converts in minutes to a Classen Turf Rake, maximizing versatility and equipment utilization
- Built Classen tough, heavy-duty commercial construction engineered to withstand years of demanding professional use
Full Specifications
Engine
Power PlantVanguard
Battery TypeSwappable
Battery Capacity1.5 kWh
Battery Charge Time75 min to 100% / 50 min to 80%
Battery Weight26 lbs
IP Rating (per IEC 60529)55
Power SourceBattery
Performance
Working Width20 in
Blade/Reel (Standard)Multipurpose
Number of Blades26
Height Adjustment Positions5
Height Adjustment Increments0.25 in
Seedbox Capacity30 lbs
Drive
TransmissionBelt Drive
Front WheelsSolid Rubber; 8 x 1.75 in
Rear WheelsSolid Rubber; 10 x 2.6 in
Dimensions & Weight
Dimensions51 x 27 x 39 in (L x W x H)
Folded Dimensions38 x 27 x 25 in (L x W x H)
Weight150 lbs
