Cozad Trailers
44 Ton Gen-X II Wide Neck Expando Trailer
Capacity
44 Ton
Deck Height
24"
Gooseneck
Mechanical Detachable
Deck Length21 ft
Overall Length42.2 ft
Empty Weight15,500 lbs
Full Specifications
Construction
Construction100% A514 T-1
Paint2 Coats Primer & Paint / White STD
Dimensions
DeckingDouglas fir (2.5")
Deck/Options21’ Length STD; 8’-6” Wide
Back-end/Options8’-6” Wide / Expands To 10’ Wide; 69” Axle Spreads
Overall Length42'-2” Estimate With 8’ Gooseneck
Deck Height24" estimate only
Options
Decking(2.5") Apitong
Gooseneck(s)9-8” With 2 Pins; Spare Tire Bracket; Full Screen; Gooseneck fenders
Deck/OptionsTool Box; Excavator Tray; Auxiliary Lighting Sockets [Front & Rear Of Deck]; Outriggers (12) Heavy Duty 3" wide; 2’ Front Loading Ramps / Steel / Aluminum
Back-end/OptionsScraper Fenders [Front / Rear Axle]; Rear Loading Ramps / 5 – 6’ / Steel / Aluminum
BrakesAir Disc (Anti-Lock)
TiresAuto Air Inflation System
Wheels8 hole / Aluminum Hub Pilot
PaintYour color
Gooseneck
Gooseneck(s)Mechanical Detachable 8' STD
Running Gear
SuspensionWalking Beam
Axles25,000 lb Oil Bath
BrakesS Cam drum brakes
Tires215/75R x 17.5 Continental
WheelsSteel Disc, 8 Hole Hub Pilot
Electrical
LightingSealco Modular Sealed Wiring System; LED Lights
Weight
Weight15,500 +/-3%
