Talbert Manufacturing
5548TA
TA Series Series
Gooseneck
Fixed
Deck Length12 ft
Overall Length36 ft
Full Specifications
Construction
Four Beam, T-1 & 80k Construction4 in. I-Beam Crossmembers on 9 in. Centers
General
80,000 lbs. Distributed 50,000 lbs. in 10 ft.1 1/2 in. Apitong Flooring
96-in. Swing RadiusHub Piloted Steel Disc Wheels
Planetary Winch with Air-Tensioner, Cable and ShackleTires: 235/75R17.5 (H) 16 PR
Wireless Winch RemoteRIDEWELL Air Ride Suspension
Wet-Line Operation7-Way Plug With LED Lights
Two-Speed Landing GearTwo Pair of Pipe Pockets Inside Side Beam Flange
Dimensions
Overall Length: 53 ft. 0 in.Keyhole Chain Slots in Side Beams and Deck Centerline; both on 36 in. Centers
Lower Deck Length: 41 ft. 6 in.Eight Keyhole Chain Slots Across Rear Approach Plate in
Lower Deck Length: 10 ft. 10 in.12 1/4 in. x 7 1/2 in., 2S/1M ABS System
Cable Roller at Front, Center of Lower DeckAxle Stops on Last Axle to Prevent Crushing when Loading
8 ft. – 6 in. Width19,480 lbs.
Capacity
Large Capacity, Lockable Tool Box on Curb Side with Chain Rack, Updated Hardware and Door SealValspar R-Cure 800® Top Coat
Talbert Manufacturing
Inventor of the hydraulic detachable gooseneck trailer. Manufacturer of heavy-capacity lowboy and specialized trailers.
Rensselaer, IndianaFounded 1938
