Talbert Manufacturing
55CC-RP
CC Series Series
Capacity
55 Ton
Deck Height
1"
Gooseneck
Hydraulic Detachable
Full Specifications
Gooseneck
Low-Profile HRG Gooseneck Design12 in. Swinging/Removable Outriggers
Dimensions
49 in. Loaded Fifth Wheel Height1/4 in. Tread Plate Over Tires
4 Beam Roller Paver Deck DesignRide Height Control: Talbert +3/-3 Valve
52 ft.- 4 in. Overall LengthSteel Disc (Hub Piloted) Wheels
24 ft.- 0 in. (23 ft. 6 in. Clear) Flat Deck3 in. High Roller Stop
22 in. Loaded Deck HeightLights And Wiring: Sealed Harness
8 ft.-6 in. Deck Width6 Lash Rings Each Side Of Deck
6 in. Loaded Road ClearanceSpring Brakes On 1 Axle
Rear Bridge Ramp 5 ft. 0 in. Sloped To DeckEstimated Weight: 22,400 lbs.
General
96 in. Swing RadiusApitong Between Main Beams
Hydraulics
Standard Support CylinderSuspension: Air Ride with Automatic And Talbert +3 in. / -3 in. Manual Control
Electrical
50 in. Wood Filled Front Loading Ramp110,000 lbs. Distributed, 100,000 lbs. In 16 ft.
Construction
1-1/2 in. Apitong FlooringValspar R-Cure 800 Red Or Black Paint
Talbert Manufacturing
Inventor of the hydraulic detachable gooseneck trailer. Manufacturer of heavy-capacity lowboy and specialized trailers.
Rensselaer, IndianaFounded 1938
