Full Specifications
Gooseneck
Fixed Gooseneck Narrow Type with High Arch ProfileTires: Low Profile 17.5 Tires / Low Profile 22.5
Removable Plate Between Gooseneck Mainbeams to Walk onTwo Pair of Pipe Pockets Inside Side Beam Flange
General
130,000 lbs. Distributed 120,000 lbs. in 16 ft.Ridewell Air Ride Suspension
120-in. Swing Radius with Alternate Settings at 108-in., 96-in.Lights: DOT Rubber Mount with Modular Harness
Starting at 59 ft. OAL (not including tail roller)Two Pair Air Pop-Up Rollers Each Side
Cable Pick-Up Eye with Winch Lug for Connection PointSix Pin Pockets on Outside Flange (Including Tail Roller)
Dimensions
8 ft.-6 in. Wide DeckAir Lift on Axles 1 and 4 ft
35-42 in. Loaded Deck HeightLash Rings Ten Each Side of Deck
Construction
2 in. Apitong FlooringAxle Stops on Last Axle to Prevent Crushing when Loading
Construction: T1 BeamsStarting at 31,100 lbs.
Talbert Manufacturing
Inventor of the hydraulic detachable gooseneck trailer. Manufacturer of heavy-capacity lowboy and specialized trailers.
Rensselaer, IndianaFounded 1938
