Talbert Manufacturing
65SA Modular
SA Series Series
Capacity
65 Ton
Axles
140-Axle
Gooseneck
Hydraulic Detachable
Full Specifications
Gooseneck
Non-Ground Bearing Gooseneck DesignTires: 275/70R22.5 (H)
120 in. Swing Radius with Connections for up to 70 in. Gooseneck ExtensionWheels: Steel Disc, Hub Piloted with Outboard Brake Drums
Hydraulics
Hydraulic Support Cylinder (Standard)Bolsters and Half Bolster on Rear Bridge
General
Front Folding / Fixed Ramps (Optional)41 in. Mainbeam / 37 in. Bolster Height
12 in. Swinging / Removable OutriggersSpring Parking Brake on Axle Two
Two Sections Chain StorageClose Coupled or 3+2 Spread Axle
Manual Raising / Lowering ValveValspar R-Cure 800 Red or Black Paint
Dimensions
28 ft. 0 in. Deck LengthBoom Well in Rear Bridge in
8 ft. 6 in. Wide DeckUp to 5 Axles Close Couple and 3+2 E2NitroTM Spread Capable
24 in. Loaded Deck Height / 6 in. Loaded Road ClearanceRemovable Axles (RA / Modular)
1/4 in. Plate Bucket Well, Last 6 ft. of DeckReinforced for Various Decks / Inserts
Construction
High Strength 100,000 psi Minimum Yield Steel12 Volt LED Sealed Light System
2 in. Apitong Flooring130,000 lb. Capacity in 14 ft (5) Axle
Capacity
Axles: 25,000 lb. Capacity140,000 lb. Capacity In 15 ft. (4) Axle Close Couple lbs
Running Gear
RIDEWELL Suspension: Air Ride with Automatic and Talbert +3 in. / -3 in. Manual ControlEstimated 3-Axle Base Trailer Weight: 31,750 lbs.
Talbert Manufacturing
Inventor of the hydraulic detachable gooseneck trailer. Manufacturer of heavy-capacity lowboy and specialized trailers.
Rensselaer, IndianaFounded 1938
