Trail King Extendable Double Drop Trailer - Detachable, Interchangeable Gooseneck - Lowboy, heavy-duty hauling equipment for global shipping
Trail King

Extendable Double Drop Trailer Featuring 4 Interchangeable Goosenecks

DDE Series

Related Products

Capacity

30 Ton

Axles

2-Axle

Deck Length34 ft
Overall Length52 ft

About This Trailer

Optional Flip NeckFor additional swing clearance and better weight distributions. Air LocksAir-activated deck locks simplify trailer extension operation. Wheel Area with Mini-Boom TroughDeeper mini-boom trough provides clearance for equipment with hitches. In addition to providing a convenient step for the operator, the removable plates provide easy access to axles. Traction aids and D-rings in transition area are standard. Extendable DeckVersatile deck lengths and lock locations, no greater than 32". Multiple air and electrical connection points for various open deck lengths. Trail King’s Commercial Detachable Gooseneck Double Drop Extendable trailer comes with the most standard equipment of any trailer of its kind on the market. These trailers are engineered to accommodate four interchangeable gooseneck styles, making this the ultimate trailer for hauling versatility. Additionally, choose from a variety of optional features, including lightweight, corrosion-resistant, aluminum options. Call our toll-free number 800-843-3324 The literature and image assets in this tab are digital assets, best for viewing online. To request print literature or media, please contact your District Sales Manager. Protect Your Investment with Our Complete Line of Services Trail King Paint Options DETACHABLE DOUBLE DROP EXTENDABLE TRAILER in augmented reality powered by JigSpace Published Date: September 30, 2026

Full Specifications

General
HED Double Drop Trailer Performance Specs80HED 2-axle
Bent style d-rings8 pair
Capacity
Capacity in 10’ (closed)60,000 lbs.
25,000 lb. capacity (5/8” wall) axles2
Gooseneck
Narrow commercial style hydraulic gooseneck10’ 2” (78” swing)
Dimensions
Overall Length52’ 11”
Deck length (closed)34’
Deck length (extended)59’ 6”
Frame
I-beam side channel with triangle cutoutsX
I-beam cross membersX
Running Gear
Axle spacing54.5”
