Steerable Dolly trailer
Trail King

Steerable Dolly

Interested in Our Hauling Solutions?

Axles

60-Axle

About This Trailer

This versatile dolly can be used with a Schnabel setup, replace standard wheel area for a steerable 13 axle configuration, or can be used in combination with a Jeep/Dolly for Bunk work. This new design allows for better maneuverability for a greater steering angle, tighter corners and less manual steering. The dolly offers remote wireless manual steer and auto alignment after manual steer for an automatic self-centering function. Call our toll-free number 800-843-3324 The literature and image assets in this tab are digital assets, best for viewing online. To request print literature or media, please contact your District Sales Manager. Trail King Steerable Dolly Protect Your Investment with Our Complete Line of Services Trail King Paint Options At Trail King, our primary goal is your success, and our trailers are customized for unique challenges. We specialize in designing custom solutions for hauling your unique loads. Talk to your District Sales Manager to learn more.

Full Specifications

Capacity
Capacity120,000
Dimensions
Width10’
Running Gear
Axle Spacing60”, 14’1” group spacing
Tires235/75R 17.5
Brakes12.25 x 7.5 (20,000 GAWR)
Poly fenders on all axlesX
Spring brakes on rear axle groupX
General
Standard Equipment120 LPSD-HS
Front Steer DesignX
Hatbox rotation60 degrees (each way)
Auto or manual steerX
Adjustable steer ratioX
Manual steerWireless or wire type remote
Auto-alignment after manual steerX
Air rideWith raising and lowering
Wide load signBrackets at rear
Aux air outlet for power toolsX
Hydraulics
Hydraulic SteeringX
Hydraulic hat box8” lift
Gooseneck
Support plate for gooseneck support armX
Electrical
Grote sealed wiring harnessX
