ClassenPower Rake
TR-20K Walk-Behind Turf Rake
Walk-Behind Series
Model TR-20K
Working Width
20 in
Engine
Kohler CH245
Power Source
Gas
Weight
135 lbs
Features
- Classen Turf Rakes are versatile and portable dethatchers. These units feature fold-down handles for easy transport and storage. Optional attachments are available for turf overseeding and vertical slice aeration.
- Multiple blade options available to dethatch any turf
- Converts in minutes to an overseeder or vertical slice aerator
- Our most compact and easy-to-use turf rake
- Fold-down handles for easy transport
- 2-Year Warranty
- Honda GX160 or Kohler CH245 engines
- Available in your choice of standard flail blade or spring tine reel
- Versatile and compact 20" turf dethatcher
- Folding handle for easy and convenient transportation
- TR-20 models features 28 heat–treated flail blades with spacing of 11/16" standard adjustable up to 1-3/8"
- 5-position, single action height adjustment.
- Heavy-duty, greasable bearings with cast iron housings
- Wheels have sealed bearings and semi–pneumatic tires
- Can be converted to a turf seeder, or vertical cutter in minutes
- Partial and Complete Reel Assemblies are available
Full Specifications
Engine
EngineKohler CH245
Power SourceGas
Performance
Working Width20 in
Blade/Reel (Standard)Flail
Number of Blades28
Height Adjustment Positions5
Height Adjustment Increments0.25 in
Drive
TransmissionBelt Drive
Front Wheels8 x 1.75 in
Front Wheels StyleSolid Rubber
Rear Wheels10 x 2.6 in
Rear Wheels StyleSolid Rubber
Dimensions & Weight
Dimensions44 x 27 x 40 in (L x W x H)
Folded Dimensions31 x 27 x 26 in (L x W x H)
Weight135 lbs
Warranty
Warranty2 years (engines warranted separately)
Classen
Classen is a Schiller Grounds Care brand of turf renovation equipment (aerators, sod cutters, overseeders and turf rakes), founded in Norfolk, Nebraska in 1973 and part of Schiller since 2004.
Southampton, PennsylvaniaSold in the U.S. through AriensCo
